Durable High-Strength Braided Rope for Versatile Tasks
This high-strength braided rope delivers durable performance for marine, construction, and DIY projects, with excellent abrasion resistance and flexibility.
Product Features
This product is made from UHMWPE or Spectra® fiber, with a construction of 8&12-Strand. It has a specific gravity of 0.975g/m², which enables it to float. The elongation at break is 3.5%, and its melting point is 145℃. Additionally, it exhibits excellent abrasion resistance and good resistance to UV and chemicals.
Main Technical Parameters
Diameter (mm) Diameter (inch) Circle (inch) Weight (LBS/100FT) Weight (KGS/100M) Breaking Strength In UHMWPE Fiber (lbs) Breaking Strength In UHMWPE Fiber (kg) Breaking Strength In Spectra® Fiber (lbs) Breaking Strength In Spectra® Fiber (kg)
3 1/8 5/16 0.4 0.6 1980 900 2500 1100
4 5/32 15/32 0.7 1.0 2900 1300 4000 1800
5 3/16 9/16 1.3 1.8 4400 2000 5400 2400
6 1/4 3/4 1.6 2.4 7500 3400 8600 3900
7 9/32 2/25 2.3 3.2 9200 4200 11000 5000
8 5/16 1 2.7 4.0 11900 5400 13700 6200
10 3/8 1-1/8 4.0 5.6 18700 8500 20900 9500
11 7/16 1-1/4 4.2 6.2 21600 9800 23900 10800
12 1/2 1-1/2 6.4 8.9 26500 12000 34000 15400
14 9/16 1-3/4 7.9 11.8 33000 14600 40500 18400
16 5/8 2 10.2 15.2 39600 18000 52800 24000
18 3/4 2-1/4 13.3 19.8 48500 22000 64400 29200
22 7/8 2-3/4 19.6 29.2 64700 29300 90800 41200
24 1 3 21.8 32.4 84600 38400 109000 49400
26 1-1/6 3-1/4 27.5 40.9 95000 43000 134000 60800
28 1-1/8 3-1/2 31.9 47.5 104000 47200 148000 67100
30 1-1/4 3-3/4 36.2 53.9 132000 59900 165000 74800
32 1-5/16 4 41.8 62.2 141000 64000 185000 84000
34 1-3/8 4-1/8 45.0 67.0 159700 72600 205000 93000
36 1-7/16 4-3/8 51.7 76.9 178000 80700 228000 103000
38 1-1/2 4-1/2 57.6 82.5 196000 89000 250800 114000
40 1-5/8 5 63.5 88.0 213000 96700 282000 128000
44 1-3/4 5-1/2 77.8 107.8 258000 117000 302000 152000
48 2 6 91.2 126.4 295000 134000 343000 173000
52 2-1/8 6-1/2 109.1 151.2 352000 160000 411000 207000
56 2-1/4 7 116.0 173.0 399000 181000 484000 244000
60 2-1/2 7-1/2 145.0 201.0 449000 204000 529000 267000
64 2-5/8 8 163.0 226.0 561000 255000 595000 300000
68 2-3/4 8-1/2 187.0 258.5 604000 291000 662000 333000
72 3 9 210.0 291.0 737000 335000 748000 377000
80 3-1/4 10 255.0 353.0 847000 385000 906000 457000
