High-Precision Hydraulic Pipe Cutter Excavator Attachment
Close-up of a silver hydraulic pipe cutting attachment with black handle, brass fittings, and precision rollers for excavator use.
Product Features
Four functions in one machine: used for stripping and cutting the outer semiconductor layer, main insulation layer, outer sheath, and chamfering of the main insulation layer.
Equipped with lubricated guide wheels, no need to apply auxiliary materials on the cable surface.
Light in weight and easy to use.
Main Technical Parameters
Model SH-50 SH-80 SH-110 SH-130 SH-160
Cable Range 15-50 40-80 35-110 50-130 90-160
Stripping Depth（mm） 1.5 1.5 2.0 2.5 2.5
Insulation Cutting Depth（mm） 0-10 0-15 0-25 0-30 0-30
Weight（kg） 1.2kg 2.2kg 3.5kg 3.5kg 5.5kg
