Portable Cable Reel Trailer for Efficient Transport
This portable cable reel trailer simplifies cable transport and deployment, featuring sturdy construction and easy maneuverability for construction and utility tasks.
Product Features
The hydraulic drum manual jack system features manual hydraulic jacks mounted on the drum lifting posts of the cable drum trailer. The jacks require no hydraulic tank and operate both jacks simultaneously. They are designed to help lift, hold and support heavy drums, keeping them securely in place so that the cable can be pulled from the drum in any application.
Main Technical Parameters
PRODUCT CODE PAYLOAD UNLADEN WEIGHT DRUM MAX DIAMETER DRUM MIN DIAMETER DRUM WIDTH
DT/1200H 1200Kg 400Kg 2150mm 750mm 1400mm
DT/1500H 1550Kg 450Kg 2150mm 750mm 1400mm
DT/2400H 2400Kg 700Kg 2550mm 1100mm 1365mm
DT/2800H 2800Kg 700Kg 2550mm 1100mm 1340mm
DT/5000H 5150Kg 1350Kg 3100mm 1350mm 1390mm
DT/7450H 7450Kg 1350Kg 3100mm 1350mm 1490mm
DT/10000H 10000Kg 2500Kg 3450mm 1500mm 2000mm
